Perspective Science - Theory and Application

This book has new and unique theories and techniques in perspective drawing unknown in any other book on the shelf. The author tried to establish the simplest methods yet geometrically proven techniques to draw precise perspective views. This book is divided into two parts, based on the viewing angle or so-called the tilt angle of the camera. Part one of the book is related to level vision (i.e. the camera is set level), which is the most popular in perspective drawing. Part two deals with the tilt angle of the camera to generate oblique perspective or so-called “Bird's and Worm's eye view”. There haven't been any perspective methods that involve a tilt angle to be preset prior to construct a perspective drawing. This book also includes a mathematical approach to establish simple vector equations to plot any 3D model based on x, y and z-coordinates. It also deals with the tilt angle of the camera to generate three- point perspective or so-called bird's and worm's eye view.
