MEM09002 - Interpret technical drawing
Usually printed in 3 - 5 business days
This unit of competency defines the skills and knowledge required to interpret technical drawings. The unit includes: Engineering Drawings; Drawing Sheets; Line Styles; Dimensions; Orthographic Projection; Sections; Scales; Abbreviations, Symbols & Notes; Reading Drawings; Manufacturer’s Catalogues. A sample competency test, quizzes and answers are included.
Details
- Publication Date
- Jan 24, 2020
- Language
- English
- Category
- Engineering
- Copyright
- All Rights Reserved - Standard Copyright License
- Contributors
- By (author): Warren Blackadder
Specifications
- Pages
- 162
- Binding Type
- Paperback Coil Bound
- Interior Color
- Black & White
- Dimensions
- A4 (8.27 x 11.69 in / 210 x 297 mm)
