2-10 MHz Shortwave receiver and 1 transistor VFO's

2-10 MHz Shortwave receiver and 1 transistor VFO's

ByKo Tilman

Text: English. A book in which a schematic for a simple 5 transistor radio (excluded the audio amplifier) for Shortwave is published. Also a few VFO's are published to make this radio operational on Shortwave. Please make the following corrections/adaptations to the text: a) page 17: the VFO signal is injected in the emitter from TS 2 b) page 25: the sentence "like the 2N2219" must be removed c) page 27: "medium power NPN transistor must be "medium power PNP transistor". On page 68 and 69: the BC 557 is a PNP (!) transistor, the arrow at the emitter is drawn in the wrong position (sorry, situation 10okt2015). All schematics are correct.Copyrighted content. Video is on You Tube, channel from Radiofun232

Details

Publication Date
Oct 22, 2011
Language
English
Category
Engineering
Copyright
All Rights Reserved - Standard Copyright License
Contributors
By (author): Ko Tilman

Specifications

Format
PDF
